ICC/IF analysis of A431 cells using GTX79473 AKAP9 antibody [17G10]. Cells were probed without (right) or with(left) an antibody.
Green : Primary antibody
Blue : Nuclei
Red : Actin
Fixation : formaldehyde
Dilution : 1:100 overnight at 4 ºC

ICC/IF analysis of HeLa cells using GTX79473 AKAP9 antibody [17G10]. Cells were probed without (right) or with(left) an antibody.
Green : Primary antibody
Blue : Nuclei
Red : Actin
Fixation : formaldehyde
Dilution : 1:20 overnight at 4ºC

ICC/IF analysis of NIH-3T3 cells using GTX79473 AKAP9 antibody [17G10]. Cells were probed without (right) or with(left) an antibody.
Green : Primary antibody
Blue : Nuclei
Red : Actin
Fixation : formaldehyde
Dilution : 1:100 overnight at 4 ºC

IHC-P analysis of human pancreas tissue using GTX79473 AKAP9 antibody [17G10].
Left : Primary antibody
Right : Negative control without primary antibody
Antigen retrieval : heat induced antigen retrieval was performed using 10mM sodium citrate (pH6.0) buffer, microwaved for 8-15 minutes
Dilution : 1:20
