Various whole cell extracts (30 μg) were separated by 10% SDS-PAGE, and the membrane was blotted with ASL antibody (GTX113629) diluted at 1:1000. The HRP-conjugated anti-rabbit IgG antibody (GTX213110-01) was used to detect the primary antibody. Corresponding RNA expression data for the same cell lines are based on Human Protein Atlas program.

ASL antibody detects ASL protein at cytoplasm by immunofluorescent analysis.
Sample: HeLa cells were fixed in 4% paraformaldehyde at RT for 15 min.
Green: ASL protein stained by ASL antibody (GTX113629) diluted at 1:500.
Red: alpha Tubulin, a cytoskeleton marker, stained by alpha Tubulin antibody [GT114] (GTX628802) diluted at 1:1000.
Blue: Hoechst 33342 staining.

ASL antibody detects ASL protein at cytoplasm by immunohistochemical analysis.
Sample: Paraffin-embedded human hepatocellular carcinoma.
ASL stained by ASL antibody (GTX113629) diluted at 1:500.
Antigen Retrieval: Citrate buffer, pH 6.0, 15 min

Immunohistochemical analysis of paraffin-embedded C2C12 xenograft, using ASL(GTX113629) antibody at 1:500 dilution.
Antigen Retrieval: Trilogy™ (EDTA based, pH 8.0) buffer, 15min

Immunofluorescence analysis of paraformaldehyde-fixed HeLa, using Argininosuccinate Lyase(GTX113629) antibody at 1:200 dilution.

Immunohistochemical analysis of paraffin-embedded U87 xenograft, using ASL(GTX113629) antibody at 1:500 dilution.
Antigen Retrieval: Trilogy™ (EDTA based, pH 8.0) buffer, 15min

ASL antibody detects ASL protein by western blot analysis.
A. 30 μg Neuro2A whole lysate/extract
B. 30 μg GL261 whole cell lysate/extract
C. 30 μg C8D30 whole cell lysate/extract
D. 30 μg NIH-3T3 whole cell lysate/extract
E. 30 μg BCL-1 whole cell lysate/extract
F. 30 μg Raw264.7 whole cell lysate/extract
G. 30 μg C2C12 whole cell lysate/extract
10% SDS-PAGE
ASL antibody (GTX113629) dilution: 1:1000
The HRP-conjugated anti-rabbit IgG antibody (GTX213110-01) was used to detect the primary antibody.
