CRMP5 antibody [N1C1] detects CRMP5 protein at cytoplasm in mouse lung by immunohistochemical analysis.
Sample: Paraffin-embedded mouse lung.
CRMP5 antibody [N1C1] (GTX112287) diluted at 1:500.

Antigen Retrieval: Citrate buffer, pH 6.0, 15 min

Immunohistochemical analysis of paraffin-embedded SW480 xenograft, using CRMP5(GTX112287) antibody at 1:500 dilution.
Antigen Retrieval: Citrate buffer, pH 6.0, 15 min

Mouse tissue extract (5 μg) was separated by 7.5% SDS-PAGE, and the membrane was blotted with CRMP5 antibody [N1C1] (GTX112287) diluted at 1:10000. The HRP-conjugated anti-rabbit IgG antibody (GTX213110-01) was used to detect the primary antibody.

CRMP5 antibody [N1C1] detects CRMP5 protein by immunofluorescent analysis.
Sample: DIV10 rat E18 primary cortical neurons were fixed in 4% paraformaldehyde at RT for 15 min.
Green: CRMP5 protein stained by CRMP5 antibody [N1C1] (GTX112287) diluted at 1:500.
Red: beta Tubulin 3/ Tuj1, stained by beta Tubulin 3/ Tuj1 antibody [GT1338] (GTX631831) diluted at 1:500.
Blue: Fluoroshield with DAPI (GTX30920).

Various whole cell extracts (30 μg) were separated by 7.5% SDS-PAGE, and the membrane was blotted with CRMP5 antibody [N1C1] (GTX112287) diluted at 1:1000. The HRP-conjugated anti-rabbit IgG antibody (GTX213110-01) was used to detect the primary antibody.
